| Chipper Capacity: |
4 – 6 CBM/Hour or 4000L – 6000L/Hour |
| Wood Diameter: |
Max. 120mm
*It changes according to the hardness of the material, the degree of bending, the density of the fiber etc. |
| Blade (Chipper Knife): |
2 Sheets |
| Triangular Blade (Hammer Knife): |
10 Sheets |
| Hydraulic Pump: |
10ml/r, 20mpa |
| Hydraulic Motor: |
0-600rpm, Max 240N*M |
| Hydraulic Oil: |
4L |
| Engine Model: |
Briggs & Stratton Vanguard V-Twin Engine (USA) |
| Displacement: |
570cc |
| Max Power: |
18HP / 3600rpm |
| Engine Type: |
V-Twin, 4 Stroke, OHV, Air-cooled |
| Bore x Stroke: |
72mm x 70mm |
| Fuel Type: |
Gasoline |
| Fuel Tank Capacity: |
8.5L |
| Oil Capacity: |
1.7L |
| Starting System: |
Recoil Start or Electric Start |
| Dimension (L x W x H): |
3000 x 1200 x 1750mm (including tower hitch) |
| Net Weight: |
280kg |
