All pumps are equipped with a maintenance free mechanical seal set of the cartridge type.
Fan-cooled, 2-pole standard motor.
Motor protection
a) Single phase: Built-in thermal overload switch.
b) Three phase: Must be connected to a motor starter in accordance with local regulations.
Ambient temperature
up to +40 °C
Pump Material:
Cast iron Base
Stainless steel pump body
Applications
Distributions of water.
Pressure boosting in high-rise building and hotels.
Pressure boosting in fire fighting systems.
Aqua farming.
Boiler feed and condensate systems.
Oil and alcohol; Glycol and coolants.
Swimming pool.
Field irrigation, sprinkler irrigation, drip-feed irrigation.
Specifications
Size Discharge
2″ x 2″
Power
11000 W / Three phase
Flow Rate
133 ~ 400 L/min
Head
158 ~ 89 meters
Manometric Suction Lift
Max. 7 meters
Liquid Temperature
Max. +90°C
Environment Temperature
Max. +40°C
Dimensions (L x W x H)
300mm x 330mm x 1418mm
Weight
150kg
