| ENGINE SPECIFICATION |
| Model |
TB26 |
| Engine Type |
Air-cooled, two-stroke, gasoline engine |
| Displacement |
25.6cc |
| Starting System |
Recoil starter (“Miracle Start”) |
| Ignition System |
TCI (transistor Capacitor Ignitor) |
| Carburetor |
Diaphragm type (overflow return) |
| Air Cleaner |
Semi-dry Type, Polyurethane Foam |
| PUMP SPECIFICATION |
| Pump |
Horizontal Gear Driving Type |
| Plunger |
1 Piece (Two way operation) |
| Cylinder |
2 Pieces |
| Diameter Of Plunger |
18mm |
| Stroke |
9mm |
| Spraying Volume |
8L per Minute |
| Pressure |
30-40 Kg |
| Chemical Tank Capacity |
25L |
| Weight |
9Kg |
