LEO SEWAGE SUBMERSIBLE WATER PUMPS XSP 9-7.5/0.25S

SPECIFICATION
Model : XSP 9-7.5/0.25S
Voltage : 220V
Max. Flow (L/min): 150
Max. Head (m): 7.5
Immersion Depth (m): 5
Power (kw / hp): 0.25 / 3.3
Outlet: 40 / 32 /25
Dimensions: 185 x 180 x 360 mm
Weight: 11 kg

Description

Applications
• Wastewater drainage in factories, construction sites and commercial facilities
• Drainage system in municipal sewage treatment plants
• Drainage station in residential quarters
• Methane pools and field irrigation in countryside

Features
• Copper winding
• Built-in thermal protector
• AISI 304 fabricated shaft
• Automatic start and stop with float switch
• Insulation class: B
• Protection class: IP68
