HKD Chain Hoist 3tx5m, 3Ø, 2.2m/min, 1.5kW, 83kg HKD0303S

Product Code: HKD0303S (Made in Taiwan)

Availability: In Stock

Model: HKD0303S (Made in Taiwan)
3ton x 5m electrical chain hoist with 3 phase motor.

Price inclusives 6%GST.

**24 months warranty on motor.
**Original Japan Chain.
**Waterproof Pendant Control IP65.

Features

Unique design permits the hoist to be hooked with minimum consumption of head room.
Each hoist is extensively tested before delivery.
a) Dynamic load test using 125% of ites rated capacity.
b) Overload voltage test.
c) Reduced voltage test.
d) Operation test.
Features of Electrical Motor
a) Class F insulation : Resistance of up to 150°C motor winding temperature.
b) Aluminium Motor Housing : Light weight and provides good heat dissipation.
Motor Brake : Instant motor brakes as soon as the electrical power is cut off.
Weight Limit Switch
48V Transformer Device: Use to prohibit unexpected condition caused by electric leakage and guarantees the safe use while raining.
Link Chain: Japan-made FEC Grade 80 super alloy steel.

Specifications
