HKD Chain Hoist 10tx5m, 3Ø, 2.7m/min, 3.0 x 2kW, 298kg HKD10004S

Model: HKD10004S (Made in Taiwan)
10ton x 5m electrical chain hoist with 3 phase motor.

Price inclusives  6%GST.

**24 months warranty on motor.
**Original Japan Chain.
**Waterproof Pendant Control IP65.

Features

• Unique design permits the hoist to be hooked with minimum consumption of head room.
• Each hoist is extensively tested before delivery.
  a) Dynamic load test using 125% of ites rated capacity.
  b) Overload voltage test.
  c) Reduced voltage test.
  d) Operation test.
• Features of Electrical Motor
  a) Class F insulation : Resistance of up to 150°C motor winding temperature.
  b) Aluminium Motor Housing : Light weight and provides good heat dissipation.
• Motor Brake : Instant motor brakes as soon as the electrical power is cut off.
• Weight Limit Switch
• 48V Transformer Device: Use to prohibit unexpected condition caused by electric leakage and guarantees the safe use while raining.
• Link Chain: Japan-made FEC Grade 80 super alloy steel.

Specifications

Accessories Included

• Chain bag
• Control cable 3meters
• Push-button switch
