FEATURES
- Quality components can withstand heavy trowelling and rough handling. Field tested under the toughest conditions and proven dependable.
- Precision machined for total balance compensation and exacting tolerances. Sealed oil-bath lubrication system.
- Chrome tubular rings are sturdier and easier to clean. Three heavy gauge steel tubes welded lateraly to ensure complete rigidity and strength along the length of the handle.
- Centrifugal safety switch shuts off the engine in the event of the operator loosing control of the unit. May also be used for normal on-off operation.
- Stainless steel blade can be used for both sides, reducing maintenance cost.
- We also assemble power trowel c/w Diesel Engine LA170
SPECIFICATIONS
| Model | FPT436 |
| Rotor Diameter (mm) | 920 |
| Finish Blade (mm) | 350 x 150 |
| Trowel Speed (rpm) | (60 - 130) |
| Weight (kg) | 75 |
ROBIN GASOLINE ENGINE
| Model | EY 20 |
| Max. output [ kw(hp) / rpm ] | 3.7 (5.0) / 4000 |
| Continuous output [ kw(hp) / rpm ] |
2.2 (3.0) / 3000 2.6 (3.5) / 3600 |
| Fuel tank capacity (ℓ) | 3.8 |
| Starting System | Recoil Starter |
| Dimension ( L x W x H ) mm | 1650 x 1000 x 930 |
