Alternator Model: EK2LAA
AC max output (KVA): 6.0
AC rated voltage (V): 230
Frequency: (Hz): 50
Voltage adjustment: AVR
Options of engines to be assembled with the above alternator:
No | Brand | Model | Fuel | Max. Output (hp) |
Fuel Tank Capacity (lit) |
Total Net Weight (kg) |
Diamension (mm) (L)x(W)x(H) |
Starting System |
4.1 | Honda | GX390 | Gasoline | 13.0 | 6.1 | 77 | 865 x 535 x 600 | Recoil |
4.2 | Robin | EX40 | Gasoline | 14.0 | 7.0 | 77 | 865 x 535 x 600 | Recoil |
