| Heavy Industrial Applications | Power Voltage | Output Current | Duty Cycle | Dimensions |
|---|---|---|---|---|
| Fabrication And Construction | 3 Phase AC415V +15% | 80-500A | 80% | D685 x H660 x W302MM |
| Heavy Manufacturing | 50 / 60Hz | OCV: 65VDC | - | - |
| Maintenance / Repair | Input Current | Output Voltage | Weight | Wire Feed Speed |
| Shipbuilding | 19.5A / 14KVA | 39V | 42KG | 3.0-24M / min |
| Refineries And Foundries | - | - | - | - |
| Pressure Tank / Vessel Fabrication | - | - | - | - |
Features
Flexible multi-process capability including stick, dc,tig, mig, flux-cored welding and carbon arc gouging with up to a 8mm carbon.
Voltage control gives you the flexibility to manually set the machine when welding aluminium, stainless steel or any time you want to set your own parameters on mild steel.
Thermal overload protection with indicator light helps prevent machine damage if the duty cycle is exceeded or airflow is blocked.
Inverter-based, dc power source has a simple-to-use operator interface providing only the necessary controls in a compact machine.
Digital voltmeter and ammeter are easy to read. this machine only includes sa 5500i with 10m wire feeder, 3m mb50 mig torch, 3m work cable and clamp, 3m stick electrode holder, 36v co2 regulator.
