Application and Features
- Ideal machine for small-middle size jobs.
- Two-speed motor.
- Included water collector ring.
- Normal Stand Column: 800 mm (31”) with 548 mm (21”) stroke.
- 50 x 50 mm (2” x 2”) square column.
Additional information
| APPLICATION MATERIAL |
Asphalt, Cement, Concrete, Cured Concrete, Green Concrete, Medium Hardness of Concrete, Reinforcement Concrete |
|---|---|
| MOTOR MODEL | |
| POWER RATED |
1,500W |
| NO. LOAD SPEED (RPM) |
700 / 1000rpm |
| RATED LOAD SPEED (RPM) |
510 / 730rpm |
| PREFERRED CORE BIT DIAMETER (MM) |
50 – 180mm |
| BASE TYPE |
Swivel Anchor (AB52) |
| BASE SIZE |
146 x 205mm |
| COLUMN HEIGHT |
1000mm |
| TRAVEL LENGTH |
748mm |
| BRAND | |
| WEIGHT |
16.3kg |
